Replacing a complete lighting package in the three kilometre Bamble and Kjørholt tunnels.Light that lasts - for any tunnel
- Designed for long lasting performance suitable with the highest corrosion classification (C5M) and anti dust canopy
- Unique luminaire design : slim, compact and lightweight
- Wide range of optics providing uniform and comfortable lighting for the safety of tunnel users
- Versatile solution with choice of luminaire sizes and remote gear boxes
Materials and Finish
Body: size S; die-cast aluminium (EN44300). Size M/L/XL; extruded aluminium (6060 T6) and end cap in die-cast aluminium (EN44300)
Enclosure: 4mm toughened glass
External screws: A2 with Geomet treatment
Glass holder: 316L stainless steel with Geomet treatment
Finish: powder coated white, RAL9016 gloss 30%
Gearbox GRP: glass fibre reinforced polyester
Bracket: 316L stainless steel
Wire: H07ZZ-F
Gearbox AL: aluminium (EN AC-44300), powder coated.
External screws: A4 stainless steel
Installation and Mounting
Luminaire mounting: ceiling with specific brackets (to be ordered separately)
Gear box: pre-wired, 1.5m cable, with bracket included.
Specification
To specify state:
Four luminaire sizes for the best balance between performance and compactness. Robust and lightweight luminiare solution suitable with highest corrosion resistant class (C5M). Easy to maintain and install thanks to its remote gear box, intuitive bracket fixation system and quick connector. The most powerful luminaire solution able to replace 600W sodium lamps in entry zone with large choice of optics and advanced lighting technology (CLO, ALO, LumGate...) to suit many tunnel configurations.
As Thorn GTLED Pro
New Product
LumExpress Product
eControl Product
▼ GTLED Pro, small, axial street comfort distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL S 12L-740 ASC IN CL1 | 3.21 | 96276232 | |||||||
| GP AL S 12L-740 ASC IO CL1 | 3.21 | 96276239 | |||||||
| GP AL S 24L-740 ASC IN CL1 | 3.29 | 96276233 | |||||||
| GP AL S 24L-740 ASC IO CL1 | 3.29 | 96276240 | |||||||
| GP AL S 36L-740 ASC IN CL1 | 3.34 | 96276234 | |||||||
| GP AL S 36L-740 ASC IO CL1 | 3.34 | 96276241 | |||||||
| GP AL S 48L-740 ASC IN CL1 | 3.40 | 96276235 | |||||||
| GP AL S 48L-740 ASC IO CL1 | 3.40 | 96276242 |
▼ GTLED Pro, small, axial extra street comfort distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL S 12L-740 AESC IN CL1 | 3.21 | 96276405 | |||||||
| GP AL S 12L-740 AESC IN CL2 | 3.21 | 96276445 | |||||||
| GP AL S 12L-740 AESC IO CL1 | 3.21 | 96276406 | |||||||
| GP AL S 24L-740 AESC IN CL1 | 3.29 | 96276408 | |||||||
| GP AL S 24L-740 AESC IN CL2 | 3.29 | 96276446 | |||||||
| GP AL S 24L-740 AESC IO CL1 | 3.29 | 96276409 | |||||||
| GP AL S 36L-740 AESC IN CL1 | 3.34 | 96276411 | |||||||
| GP AL S 36L-740 AESC IN CL2 | 3.34 | 96276447 | |||||||
| GP AL S 36L-740 AESC IO CL1 | 3.34 | 96276412 | |||||||
| GP AL S 48L-740 AESC IN CL1 | 3.40 | 96276413 | |||||||
| GP AL S 48L-740 AESC IN CL2 | 3.40 | 96276448 |
▼ GTLED Pro, small, counter beam distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL S 24L-740 CB2 IN CL1 | 3.29 | 96276361 | |||||||
| GP AL S 24L-740 CB2 IO CL1 | 3.29 | 96276362 | |||||||
| GP AL S 36L-740 CB2 IN CL1 | 3.34 | 96276363 | |||||||
| GP AL S 36L-740 CB2 IO CL1 | 3.34 | 96276364 | |||||||
| GP AL S 48L-740 CB2 IN CL1 | 10.01 | 96276365 | |||||||
| GP AL S 48L-740 CB2 IO CL1 | 10.01 | 96276366 |
▼ GTLED Pro, medium, axial street comfort distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL M 72L-740 ASC IN CL1 | 10.00 | 96276619 | |||||||
| GP AL M 72L-740 ASC IO CL1 GB-AL | 10.00 | 96276620 |
▼ GTLED Pro, medium, axial extra street comfort distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL M 72L-740 AESC IN CL1 | 10.00 | 96276407 | |||||||
| GP AL M 72L-740 AESC IO CL1 GB-AL | 10.00 | 96276410 |
▼ GTLED Pro, medium, axial narrow road distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL M 72L-740 NR-S IN CL1 | 10.00 | 96276367 | |||||||
| GP AL M 72L-740 NR-S IO CL1 GB-AL | 10.00 | 96276368 |
▼ GTLED Pro, medium, axial road comfort distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL M 72L-740 RC-S IN CL1 | 10.00 | 96276369 | |||||||
| GP AL M 72L-740 RC-S IO CL1 GB-AL | 10.00 | 96276370 |
▼ GTLED Pro, medium, counter beam distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| <GP AL M 72L-740 CB2-LV IO CL1 GB-AL | 10.00 | 96276428 | |||||||
| GP AL M 72L-740 CB2 LV IO CL1 GB-AL | 10.00 | 96276243 | |||||||
| GP AL M 72L-740 CB2-LV IN CL1 | 10.00 | 96276236 | |||||||
| GP AL M 72L-740 CB2-LV IN CL1 GB-AL | 10.00 | 96276429 |
▼ GTLED Pro, large, axial street comfort distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL L 144L-740 ASC IN CL1 | 12.21 | 96276374 |
▼ GTLED Pro, large, axial extra street comfort distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL L 144L-740 AESC IN CL1 | 12.21 | 96276373 |
▼ GTLED Pro, large, axial narrow road distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL L 144L-740 NR-S IN CL1 | 12.21 | 96276371 |
▼ GTLED Pro, large, axial road comfort distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL L 144L-740 RC-S IN CL1 | 12.21 | 96276372 |
▼ GTLED Pro, large, counter beam distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL L 144L-740 CB2-LV IN CL1 | 12.21 | 96276237 | |||||||
| GP AL L 144L-740 CB2-LV IN CL1 GB-AL | 12.21 | 96276431 |
▼ GTLED Pro, extra large, axial extra street comfort distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL XL 216L-740 AESC IN CL1 | 17.23 | 96276379 |
▼ GTLED Pro, extra large, axial narrow road distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL XL 216L-740 NR-S IN CL1 | 17.23 | 96276375 |
▼ GTLED Pro, extra large, axial road comfort distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL XL 216L-740 RC-S IN CL1 | 17.23 | 96276377 |
▼ GTLED Pro, extra large, counter beam distribution
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP AL XL 216L-740 CB2-LV IN CL1 | 17.23 | 96276238 | |||||||
| GP AL XL 216L-740 CB2-LV IN CL1 GB-AL | 17.23 | 96276433 |
▼ GTLED Pro, gear box, plastic
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP GB GRP 1x160W OUT1-105 W1,5 CL1 | 6.61 | 96276223 | |||||||
| GP GB GRP 1x160W OUT1-35 W1,5 CL1 | 6.61 | 96276385 | |||||||
| GP GB GRP 1x160W OUT1-50 W1,5 CL1 | 6.61 | 96276386 | |||||||
| GP GB GRP 1x160W OUT1-70 W1,5 CL1 | 6.61 | 96276387 | |||||||
| GP GB GRP 2x120W OUT1-105 W1,5 CL1 | 7.41 | 96276224 | |||||||
| GP GB GRP 2x120W OUT1-35 W1,5 CL1 | 7.41 | 96276388 | |||||||
| GP GB GRP 2x120W OUT1-50 W1,5 CL1 | 7.41 | 96276389 | |||||||
| GP GB GRP 2x120W OUT1-70 W1,5 CL1 | 7.41 | 96276390 | |||||||
| GP GB GRP 2x120W OUT2-105 W1,5 CL1 | 7.72 | 96276225 | |||||||
| GP GB GRP 2x120W OUT2-35 W1,5 CL1 | 7.72 | 96276391 | |||||||
| GP GB GRP 2x120W OUT2-50 W1,5 CL1 | 7.72 | 96276392 | |||||||
| GP GB GRP 2x120W OUT2-70 W1,5 CL1 | 7.72 | 96276393 | |||||||
| GP GB GRP 2x160W OUT1-35 W1,5 CL1 | 7.66 | 96276394 | |||||||
| GP GB GRP 2x160W OUT1-50 W1,5 CL1 | 7.66 | 96276395 | |||||||
| GP GB GRP 2x160W OUT1-70 W1,5 CL1 | 7.66 | 96276227 | |||||||
| GP GB GRP 2x160W OUT2-105 W1,5 CL1 | 7.79 | 96276226 | |||||||
| GP GB GRP 2x160W OUT2-35 W1,5 CL1 | 7.79 | 96276396 | |||||||
| GP GB GRP 2x160W OUT2-50 W1,5 CL1 | 7.79 | 96276397 | |||||||
| GP GB GRP 2x160W OUT2-70 W1,5 CL1 | 7.79 | 96276398 |
▼ GTLED Pro accessories
| Description | Wt (kg) | SAP Code | |||||||
|---|---|---|---|---|---|---|---|---|---|
| GP M/L/XL 72-216L BRACKET KIT (x1) | 0.95 | 96631713 | |||||||
| GP S 12-48L BRACKET KIT (x1) | 0.54 | 96631712 |
