LED spotlight for 3-phase track installations or CONTUS continuous-row systems

  • GRAFFITI offers two lumen packages in one compact size (Ø95mm) 2800lm and 3600lm in CRI>90 and in two colour temperatures 3.000K and 4.000K
  • Available for both key lighting infrastructures: 3-phase track and Thorn CONTUS trunking
  • High-quality, low-glare spotlight for Retail applications with up to 130lm/W for reduced energy cost
  • Integrated in-house driver for an overall clean design aesthetic

Materials and Finish

Housing: Die-cast aluminium
Colour: Black or white microtextured paint
Fronting: Black
Reflector: Aluminium sputtered PC reflector

Installation and Mounting

3GU version: spotlight can be installed and de-installed tool free via 3-phase track adapter
Wall mounting not permitted; not suitable for point outlet
CONTUS version: spotlight fixed via CONTUS to the trunking using CLIX technology

Specification

To specify state:
LED spotlight with stabilised colour temperature (warm white / cool white), optimised for high-output accent lighting. Switchable luminaire, correlated colour temperature is 3000/4000K with CRI>90 and a chromaticity tolerance of 3. Lifetime is 50,000 hours (L70). Spotlight rotatable through 360°and pivotable through 90°. Aluminium sputtered PC reflector, highly specular, iridescence-free, designed to be interchangeable and retrofitted.
3GU version: can be installed and de-installed tool-free via 3-phase track adapter
CONTUS version: spotlight fixed via CONTUS adapter plate to the trunking using CLIX technology
As Thorn Graffiti

  • New Product
New Product
LumExpress Product
eControl Product

Graffiti, 3GU spot

Description   TypeWt (kg)SAP Code
<GRAFFITI 2800-930 SWI 3GU SP BKLED0.7196108677
<GRAFFITI 2800-930 SWI 3GU SP BK 12XLED0.7196108623
<GRAFFITI 2800-930 SWI 3GU SP WHLED0.7196108674
<GRAFFITI 2800-930 SWI 3GU SP WH 12XLED0.7196108620
<GRAFFITI 2800-940 SWI 3GU SP BKLED0.7196108683
<GRAFFITI 2800-940 SWI 3GU SP BK 12XLED0.7196108629
<GRAFFITI 2800-940 SWI 3GU SP WHLED0.7196108680
<GRAFFITI 2800-940 SWI 3GU SP WH 12XLED0.7196108626
<GRAFFITI 3600-930 SWI 3GU SP BKLED0.7196108689
<GRAFFITI 3600-930 SWI 3GU SP WHLED0.7196108686
<GRAFFITI 3600-940 SWI 3GU SP BKLED0.7196108695
<GRAFFITI 3600-940 SWI 3GU SP WHLED0.7196108692
GRAFFITI 2800-930HE SWI 3GU FL BKLED0.7196108754
GRAFFITI 2800-930HE SWI 3GU SP BKLED0.7196108753
GRAFFITI 2800-930HE SWI 3GU SP BK 12XLED0.7196108717
GRAFFITI 2800-930HE SWI 3GU SP WHLED0.7196108750
GRAFFITI 2800-930HE SWI 3GU SP WH 12XLED0.7196108714
GRAFFITI 2800-940HE HF 3GU SP WH 12XLED0.7196108720
GRAFFITI 2800-940HE SWI 3GU SP BKLED0.7196108723
GRAFFITI 2800-940HE SWI 3GU SP BKLED0.7196108759
GRAFFITI 2800-940HE SWI 3GU SP WHLED0.7196108756
GRAFFITI 3600-930 SWI 3GU SP BK 12XLED0.7196108635
GRAFFITI 3600-930 SWI 3GU SP WH 12XLED0.7196108632
GRAFFITI 3600-930HE SWI 3GU SP BKLED0.7196108765
GRAFFITI 3600-930HE SWI 3GU SP BK 12XLED0.7196108729
GRAFFITI 3600-930HE SWI 3GU SP WHLED0.7196108762
GRAFFITI 3600-930HE SWI 3GU SP WH 12XLED0.7196108726
GRAFFITI 3600-940 SWI 3GU SP BK 12XLED0.7196108641
GRAFFITI 3600-940 SWI 3GU SP WH 12XLED0.7196108638
GRAFFITI 3600-940HE SWI 3GU SP BKLED0.7196108771
GRAFFITI 3600-940HE SWI 3GU SP BK 12XLED0.7196108735
GRAFFITI 3600-940HE SWI 3GU SP WHLED0.7196108768
GRAFFITI 3600-940HE SWI 3GU SP WH 12XLED0.7196108732

Graffiti, 3GU flood

Description   TypeWt (kg)SAP Code
<GRAFFITI 2800-930 SWI 3GU FL BKLED0.7196108678
<GRAFFITI 2800-930 SWI 3GU FL BK 12XLED0.7196108624
<GRAFFITI 2800-930 SWI 3GU FL WHLED0.7196108675
<GRAFFITI 2800-930 SWI 3GU FL WH 12XLED0.7196108621
<GRAFFITI 2800-940 SWI 3GU FL BKLED0.7196108684
<GRAFFITI 2800-940 SWI 3GU FL BK 12XLED0.7196108630
<GRAFFITI 2800-940 SWI 3GU FL WHLED0.7196108681
<GRAFFITI 2800-940 SWI 3GU FL WH 12XLED0.7196108627
<GRAFFITI 3600-930 SWI 3GU FL BKLED0.7196108690
<GRAFFITI 3600-930 SWI 3GU FL WHLED0.7196108687
<GRAFFITI 3600-940 SWI 3GU FL BKLED0.7196108696
<GRAFFITI 3600-940 SWI 3GU FL WHLED0.7196108693
GRAFFITI 2800-930HE SWI 3GU FL BK 12XLED0.7196108718
GRAFFITI 2800-930HE SWI 3GU FL WHLED0.7196108751
GRAFFITI 2800-930HE SWI 3GU FL WH 12XLED0.7196108715
GRAFFITI 2800-940HE SWI 3GU FL BKLED0.7196108760
GRAFFITI 2800-940HE SWI 3GU FL BK 12XLED0.7196108724
GRAFFITI 2800-940HE SWI 3GU FL WHLED0.7196108757
GRAFFITI 2800-940HE SWI 3GU FL WH 12XLED0.7196108721
GRAFFITI 3600-930 SWI 3GU FL BK 12XLED0.7196108636
GRAFFITI 3600-930 SWI 3GU FL WH 12XLED0.7196108633
GRAFFITI 3600-930HE SWI 3GU FL BKLED0.7196108766
GRAFFITI 3600-930HE SWI 3GU FL BK 12XLED0.7196108730
GRAFFITI 3600-930HE SWI 3GU FL WHLED0.7196108763
GRAFFITI 3600-930HE SWI 3GU FL WH 12XLED0.7196108727
GRAFFITI 3600-940 SWI 3GU FL BK 12XLED0.7196108642
GRAFFITI 3600-940 SWI 3GU FL WH 12XLED0.7196108639
GRAFFITI 3600-940HE SWI 3GU FL BKLED0.7196108772
GRAFFITI 3600-940HE SWI 3GU FL BK 12XLED0.7196108736
GRAFFITI 3600-940HE SWI 3GU FL WHLED0.7196108769
GRAFFITI 3600-940HE SWI 3GU FL WH 12XLED0.7196108733

Graffiti, 3GU wide flood

Description   TypeWt (kg)SAP Code
<GRAFFITI 2800-930 SWI 3GU WFL BKLED0.7196108679
<GRAFFITI 2800-930 SWI 3GU WFL BK 12XLED0.7196108625
<GRAFFITI 2800-930 SWI 3GU WFL WHLED0.7196108676
<GRAFFITI 2800-930 SWI 3GU WFL WH 12XLED0.7196108622
<GRAFFITI 2800-940 SWI 3GU WFL BKLED0.7196108685
<GRAFFITI 2800-940 SWI 3GU WFL BK 12XLED0.7196108631
<GRAFFITI 2800-940 SWI 3GU WFL WHLED0.7196108682
<GRAFFITI 2800-940 SWI 3GU WFL WH 12XLED0.7196108628
<GRAFFITI 3600-930 SWI 3GU WFL BKLED0.7196108691
<GRAFFITI 3600-930 SWI 3GU WFL WHLED0.7196108688
<GRAFFITI 3600-940 SWI 3GU WFL BKLED0.7196108697
<GRAFFITI 3600-940 SWI 3GU WFL WHLED0.7196108694
GRAFFITI 2800-930HE SWI 3GU WFL BKLED0.7196108755
GRAFFITI 2800-930HE SWI 3GU WFL BK 12XLED0.7196108719
GRAFFITI 2800-930HE SWI 3GU WFL WHLED0.7196108752
GRAFFITI 2800-930HE SWI 3GU WFL WH 12XLED0.7196108716
GRAFFITI 2800-940HE SWI 3GU WFL BKLED0.7196108761
GRAFFITI 2800-940HE SWI 3GU WFL BK 12XLED0.7196108725
GRAFFITI 2800-940HE SWI 3GU WFL WHLED0.7196108758
GRAFFITI 2800-940HE SWI 3GU WFL WH 12XLED0.7196108722
GRAFFITI 3600-930 SWI 3GU WFL BK 12XLED0.7196108637
GRAFFITI 3600-930 SWI 3GU WFL WH 12XLED0.7196108634
GRAFFITI 3600-930HE SWI 3GU WFL BKLED0.7196108767
GRAFFITI 3600-930HE SWI 3GU WFL BK 12XLED0.7196108731
GRAFFITI 3600-930HE SWI 3GU WFL WHLED0.7196108764
GRAFFITI 3600-930HE SWI 3GU WFL WH 12XLED0.7196108728
GRAFFITI 3600-940 SWI 3GU WFL BK 12XLED0.7196108643
GRAFFITI 3600-940 SWI 3GU WFL WH 12XLED0.7196108640
GRAFFITI 3600-940HE SWI 3GU WFL BKLED0.7196108773
GRAFFITI 3600-940HE SWI 3GU WFL BK 12XLED0.7196108737
GRAFFITI 3600-940HE SWI 3GU WFL WHLED0.7196108770
GRAFFITI 3600-940HE SWI 3GU WFL WH 12XLED0.7196108734

Graffiti, CONT spot

Graffiti, CONT flood

Graffiti, CONT wide flood

Graffiti, accessories

Description   Wt (kg)SAP Code
GRAFFITI HONEYCOMB LOUVRE BK0.0396108656
GRAFFITI PROTECTION GLASS0.0496108657
