  • E/Fact — EFACT R2 7L50 ACC 22D RGB DMX RS SF

E/Fact / EFACT R2 7L50 ACC 22D RGB DMX RS SF

96271705

▼ Data Sheet

A large round ground recessed luminaire. 7 LED(s) driven at 500mA by integral driver, beam angle for walkover guidance applications. Tilting angle adjustment of ±15°. Body: die-cast aluminium with powdered paint finish. Frame: stainless steel, 2mm thick. Front glass: semi-frosted toughened sodic glass, 12mm thick, surface temperature complies with EN60598-2-13. Recessing box: polypropylene. Rated IP67, class I electrical. Maximum static load 1000kg. Complete with RGB LEDs. DMX drivers included.

Dimensions: Ø260 x 200 mm
Luminaire input power: 10 W
Luminaire luminous flux: 316 lm
Luminaire efficacy: 32 lm/W
Weight: 6.13 kg

Mode selection
  • Lamp position:STD - standard
  • Light Source:LED
  • Luminaire luminous flux*:316 lm
  • Luminaire efficacy*:32 lm/W
  • Colour Rendering Index min.:80
  • Rated median useful life*: 50000h at 25°C
  • Ballast:1x EL2
  • Luminaire input power*:10 W
  • Dimming:FO
  • LED
  • CE
  • EAC
  • GLedReP
  • IK09
  • IP67
  • LLedNr
  • RCM
  • Electrical class I

▼ Photometry

Photometric configuration
