  • Linn — LINN SQ LED 2L35 832

Linn / LINN SQ LED 2L35 832

96262124

▶Change configuration

  • Base: 96262124 — LINN SQ LED 2L35 832
  • Louvre/diffuser/cover: 96262129 — LINN SQ FR GL FRAME

▼ Data Sheet

A square, Recessed LED luminaire for pathway lighting applications. Electronic, fixed output control gear. Class I electrical, IP65, IK10. Body: die-cast aluminium, painted dark grey (Akzo Nobel 900). Glass: tempered glass, 6mm thick. Recessed housing (required, to be ordered separately): polypropylene. Complete with 3200K LED

Dimensions: 106 x 106 x 83 mm

Weight: 0.3 kg

Equipped with:

  • Frosted glass frame for square Linn luminaire.
Mode selection
    • CE
    • EAC
    • 850°
    • IK10
    • IP65
    • RCM
    • Electrical class I
    • Ta=35°C
