Areaflood Pro
Projects
Renovation of public lighting - City of Kikinda, SerbiaGeneral purpose area floodlight with superior optical performance and control
- Best optical performance and efficiency
- Optimal control of light (0cd at 90°, minimal spill light) for the comfort of inhabitants
- Compactness and reduced weight to avoid additional structural costs in retrofit installations
- No maintenance floodlight thanks to 100k hrs rated lifetime on both drivers and LEDs
- Medium and large versions are compliant with DIN 18032-3:1997-04 (Sports halls - halls for gymnastics, games and multi-purpose use - Part 3: Testing of safety against ball throwing)
Materials and Finish
Body and stirrup: die-cast aluminium (EN AC-44300) light grey 150 sanded textured (close to RAL9006). Standard corrosion class C5 according to ISO 9223:2012.
Glass: 4mm toughened
Screws: stainless steel
Installation and Mounting
For small version, stirrup fixed by a single bolt through one Ø22mm hole or two Ø12mm holes. For medium and large versions, it is fixed by a single bolt through one Ø22mm hole or two Ø15mm holes or two Ø12mm holes. Stirrup is reversible for hang down position. Integral gear tray, access by removal of canopy via 4 allen screws. Cable gland for Ø8-12mm cable. Optional spigot adaptors available separately for post top mounting.
Typical installation position is horizontal, although limited tilt may be useful to optimise lighting distributions. Uplighting position allowed. A special surface treatment is required for swimming pool installation.
Specification
To specify state:
Asymmetrical LED floodlight for general purpose area lighting and sports lighting. 3 sizes available, lumen package from 5 to 37klm, with a range of 5 light distributions. High performance floodlight with excellent control of light (0cd at 90°), high mechanical resistance (IP66, IK08) and full controls compatibilty (dimming, lighting controls). Available in electrical class I and class II.
As Thorn Areaflood Pro.
New Product
LumExpress Product
eControl Product
▼ Areaflood Pro Small, Asymmetric optic 40°, bi-power
| Description | Luminaire power (W) | Luminaire output (lm) | Type | Wt (kg) | SAP Code | ||||
|---|---|---|---|---|---|---|---|---|---|
| AFP S 24L35-740 A4 BS 3550 CL1 GY | 28 | 4276 | LED | 6.20 | 96644710 | ||||
| AFP S 24L35-740 A4 BS 3550 CL2 GY | 28 | 4276 | LED | 6.20 | 96644711 | ||||
| AFP S 24L50-740 A4 BS 3550 CL1 GY | 38 | 5877 | LED | 6.20 | 96644730 | ||||
| AFP S 24L50-740 A4 BS 3550 CL2 GY | 38 | 5877 | LED | 6.20 | 96644731 | ||||
| AFP S 24L70-740 A4 BS 3550 CL1 GY | 52 | 7862 | LED | 6.20 | 96644750 | ||||
| AFP S 24L70-740 A4 BS 3550 CL2 GY | 52 | 7862 | LED | 6.20 | 96644751 | ||||
| AFP S 36L35-740 A4 BS 3550 CL1 GY | 39 | 6379 | LED | 6.30 | 96644770 | ||||
| AFP S 36L35-740 A4 BS 3550 CL2 GY | 39 | 6379 | LED | 6.30 | 96644771 | ||||
| AFP S 36L50-740 A4 BS 3550 CL1 GY | 55 | 8731 | LED | 6.30 | 96644790 | ||||
| AFP S 36L50-740 A4 BS 3550 CL2 GY | 55 | 8731 | LED | 6.30 | 96644791 | ||||
| AFP S 36L70-740 A4 BS 3550 CL1 GY | 77 | 11594 | LED | 6.30 | 96644820 | ||||
| AFP S 36L70-740 A4 BS 3550 CL2 GY | 77 | 11594 | LED | 6.30 | 96644821 |
▼ Areaflood Pro Small, Asymmetric optic 40°, DALI dimmable
| Description | Luminaire power (W) | Luminaire output (lm) | Type | Wt (kg) | SAP Code | ||||
|---|---|---|---|---|---|---|---|---|---|
| AFP S 24L50-740 A4 HFX CL1 GY | 38 | 5877 | LED | 6.20 | 96644745 | ||||
| AFP S 24L50-740 A4 HFX CL2 GY | 38 | 5877 | LED | 6.20 | 96644740 | ||||
| AFP S 24L70-740 A4 HFX CL1 GY | 52 | 7862 | LED | 6.20 | 96644765 | ||||
| AFP S 24L70-740 A4 HFX CL2 GY | 52 | 7862 | LED | 6.20 | 96644760 | ||||
| AFP S 36L35-740 A4 HFX CL1 GY | 39 | 6379 | LED | 6.30 | 96644785 | ||||
| AFP S 36L35-740 A4 HFX CL2 GY | 39 | 6379 | LED | 6.30 | 96644780 | ||||
| AFP S 36L50-740 A4 HFX CL1 GY | 55 | 8731 | LED | 6.30 | 96644815 | ||||
| AFP S 36L50-740 A4 HFX CL2 GY | 55 | 8731 | LED | 6.30 | 96644810 | ||||
| AFP S 36L70-740 A4 HFX CL1 GY | 77 | 11594 | LED | 6.30 | 96644853 | ||||
| AFP S 36L70-740 A4 HFX CL2 GY | 77 | 11594 | LED | 6.30 | 96644848 |
▼ Areaflood Pro Small, Asymmetric optic 50°, bi-power
| Description | Luminaire power (W) | Luminaire output (lm) | Type | Wt (kg) | SAP Code | ||||
|---|---|---|---|---|---|---|---|---|---|
| AFP S 24L50-740 A5 BS 3550 CL1 GY | 38 | 5718 | LED | 6.18 | 96644732 | ||||
| AFP S 24L50-740 A5 BS 3550 CL2 GY | 38 | 5718 | LED | 6.20 | 96644733 | ||||
| AFP S 24L70-740 A5 BS 3550 CL1 GY | 52 | 7650 | LED | 6.18 | 96644752 | ||||
| AFP S 24L70-740 A5 BS 3550 CL2 GY | 52 | 7650 | LED | 6.20 | 96644753 | ||||
| AFP S 36L35-740 A5 BS 3550 CL1 GY | 39 | 6207 | LED | 6.22 | 96644772 | ||||
| AFP S 36L35-740 A5 BS 3550 CL2 GY | 39 | 6207 | LED | 6.24 | 96644773 | ||||
| AFP S 36L50-740 A5 BS 3550 CL1 GY | 55 | 8495 | LED | 6.22 | 96644792 | ||||
| AFP S 36L50-740 A5 BS 3550 CL2 GY | 55 | 8495 | LED | 6.24 | 96644793 | ||||
| AFP S 36L70-740 A5 BS 3550 CL1 GY | 77 | 11281 | LED | 6.27 | 96644822 | ||||
| AFP S 36L70-740 A5 BS 3550 CL2 GY | 77 | 11281 | LED | 6.29 | 96644823 |
▼ Areaflood Pro Small, Asymmetric optic 50°, DALI dimmable
| Description | Luminaire power (W) | Luminaire output (lm) | Type | Wt (kg) | SAP Code | ||||
|---|---|---|---|---|---|---|---|---|---|
| AFP S 24L50-740 A5 HFX CL1 GY | 38 | 5718 | LED | 6.16 | 96644746 | ||||
| AFP S 24L50-740 A5 HFX CL2 GY | 38 | 5718 | LED | 6.20 | 96644741 | ||||
| AFP S 24L70-740 A5 HFX CL1 GY | 52 | 7650 | LED | 6.16 | 96644766 | ||||
| AFP S 24L70-740 A5 HFX CL2 GY | 52 | 7650 | LED | 6.20 | 96644761 | ||||
| AFP S 36L35-740 A5 HFX CL1 GY | 39 | 6207 | LED | 6.20 | 96644786 | ||||
| AFP S 36L35-740 A5 HFX CL2 GY | 39 | 6207 | LED | 6.23 | 96644781 | ||||
| AFP S 36L50-740 A5 HFX CL1 GY | 55 | 8495 | LED | 6.20 | 96644816 | ||||
| AFP S 36L50-740 A5 HFX CL2 GY | 55 | 8495 | LED | 6.23 | 96644811 | ||||
| AFP S 36L70-740 A5 HFX CL1 GY | 77 | 11281 | LED | 6.25 | 96644854 | ||||
| AFP S 36L70-740 A5 HFX CL2 GY | 77 | 11281 | LED | 6.29 | 96644849 |
▼ Areaflood Pro Small, Asymmetric optic 60°, bi-power
| Description | Luminaire power (W) | Luminaire output (lm) | Type | Wt (kg) | SAP Code | ||||
|---|---|---|---|---|---|---|---|---|---|
| AFP S 24L50-740 A6 BS 3550 CL1 GY | 38 | 5792 | LED | 6.18 | 96644734 | ||||
| AFP S 24L50-740 A6 BS 3550 CL2 GY | 38 | 5792 | LED | 6.20 | 96644735 | ||||
| AFP S 24L70-740 A6 BS 3550 CL1 GY | 52 | 7748 | LED | 6.18 | 96644754 | ||||
| AFP S 24L70-740 A6 BS 3550 CL2 GY | 52 | 7748 | LED | 6.20 | 96644755 | ||||
| AFP S 36L35-740 A6 BS 3550 CL1 GY | 39 | 6287 | LED | 6.22 | 96644774 | ||||
| AFP S 36L35-740 A6 BS 3550 CL2 GY | 39 | 6287 | LED | 6.24 | 96644775 | ||||
| AFP S 36L50-740 A6 BS 3550 CL1 GY | 55 | 8605 | LED | 6.22 | 96644794 | ||||
| AFP S 36L50-740 A6 BS 3550 CL2 GY | 55 | 8605 | LED | 6.24 | 96644795 | ||||
| AFP S 36L70-740 A6 BS 3550 CL1 GY | 77 | 11426 | LED | 6.27 | 96644824 | ||||
| AFP S 36L70-740 A6 BS 3550 CL2 GY | 77 | 11426 | LED | 6.29 | 96644825 |
▼ Areaflood Pro Small, Asymmetric optic 60°, DALI dimmable
| Description | Luminaire power (W) | Luminaire output (lm) | Type | Wt (kg) | SAP Code | ||||
|---|---|---|---|---|---|---|---|---|---|
| AFP S 24L50-740 A6 HFX CL1 GY | 38 | 5792 | LED | 6.16 | 96644747 | ||||
| AFP S 24L50-740 A6 HFX CL2 GY | 38 | 5792 | LED | 6.20 | 96644742 | ||||
| AFP S 24L70-740 A6 HFX CL1 GY | 52 | 7748 | LED | 6.16 | 96644767 | ||||
| AFP S 24L70-740 A6 HFX CL2 GY | 52 | 7748 | LED | 6.20 | 96644762 | ||||
| AFP S 36L35-740 A6 HFX CL1 GY | 39 | 6287 | LED | 6.20 | 96644787 | ||||
| AFP S 36L35-740 A6 HFX CL2 GY | 39 | 6287 | LED | 6.23 | 96644782 | ||||
| AFP S 36L50-740 A6 HFX CL1 GY | 55 | 8605 | LED | 6.20 | 96644817 | ||||
| AFP S 36L50-740 A6 HFX CL2 GY | 55 | 8605 | LED | 6.23 | 96644812 | ||||
| AFP S 36L70-740 A6 HFX CL1 GY | 77 | 11426 | LED | 6.25 | 96644855 | ||||
| AFP S 36L70-740 A6 HFX CL2 GY | 77 | 11426 | LED | 6.29 | 96644850 |
▼ Areaflood Pro Medium, Asymmetric optic 40°, bi-power
| Description | Luminaire power (W) | Luminaire output (lm) | Type | Wt (kg) | SAP Code | ||||
|---|---|---|---|---|---|---|---|---|---|
| AFP M 48L35-740 A4 BS 3550 CL1 GY | 50 | 8552 | LED | 13.00 | 96644878 | ||||
| AFP M 48L35-740 A4 BS 3550 CL2 GY | 50 | 8552 | LED | 12.96 | 96644879 | ||||
| AFP M 48L50-740 A4 BS 3550 CL1 GY | 72 | 11754 | LED | 13.01 | 96644898 | ||||
| AFP M 48L50-740 A4 BS 3550 CL2 GY | 72 | 11754 | LED | 13.63 | 96644899 | ||||
| AFP M 48L70-740 A4 BS 3550 CL1 GY | 101 | 15724 | LED | 13.68 | 96644918 | ||||
| AFP M 48L70-740 A4 BS 3550 CL2 GY | 101 | 15724 | LED | 13.63 | 96644919 | ||||
| AFP M 72L35-740 A4 BS 3550 CL1 GY | 75 | 12784 | LED | 13.81 | 96644938 | ||||
| AFP M 72L35-740 A4 BS 3550 CL2 GY | 75 | 12784 | LED | 13.77 | 96644939 | ||||
| AFP M 72L50-740 A4 BS 3550 CL1 GY | 107 | 17526 | LED | 13.81 | 96644958 | ||||
| AFP M 72L50-740 A4 BS 3550 CL2 GY | 107 | 17526 | LED | 13.77 | 96644959 | ||||
| AFP M 72L70-740 A4 BS 3550 CL1 GY | 150 | 23339 | LED | 13.81 | 96644988 | ||||
| AFP M 72L70-740 A4 BS 3550 CL2 GY | 150 | 23339 | LED | 13.77 | 96644989 |
▼ Areaflood Pro Medium, Asymmetric optic 40°, DALI dimmable
| Description | Luminaire power (W) | Luminaire output (lm) | Type | Wt (kg) | SAP Code | ||||
|---|---|---|---|---|---|---|---|---|---|
| AFP M 48L35-740 A4 HFX CL1 GY | 50 | 8552 | LED | 13.97 | 96644893 | ||||
| AFP M 48L35-740 A4 HFX CL2 GY | 50 | 8552 | LED | 11.77 | 96644888 | ||||
| AFP M 48L50-740 A4 HFX CL1 GY | 72 | 11754 | LED | 13.97 | 96644913 | ||||
| AFP M 48L50-740 A4 HFX CL2 GY | 72 | 11754 | LED | 12.95 | 96644908 | ||||
| AFP M 48L70-740 A4 HFX CL1 GY | 101 | 15724 | LED | 13.65 | 96644933 | ||||
| AFP M 48L70-740 A4 HFX CL2 GY | 101 | 15724 | LED | 13.62 | 96644928 | ||||
| AFP M 72L35-740 A4 HFX CL1 GY | 75 | 12784 | LED | 13.78 | 96644953 | ||||
| AFP M 72L35-740 A4 HFX CL2 GY | 75 | 12784 | LED | 13.75 | 96644948 | ||||
| AFP M 72L50-740 A4 HFX CL1 GY | 107 | 17526 | LED | 13.78 | 96644983 | ||||
| AFP M 72L50-740 A4 HFX CL2 GY | 107 | 17526 | LED | 13.75 | 96644978 | ||||
| AFP M 72L70-740 A4 HFX CL1 GY | 150 | 23339 | LED | 13.78 | 96645021 | ||||
| AFP M 72L70-740 A4 HFX CL2 GY | 150 | 23339 | LED | 13.75 | 96645016 |
▼ Areaflood Pro Medium, Asymmetric optic 50°, bi-power
| Description | Luminaire power (W) | Luminaire output (lm) | Type | Wt (kg) | SAP Code | ||||
|---|---|---|---|---|---|---|---|---|---|
| AFP M 48L35-740 A5 BS 3550 CL1 GY | 50 | 8321 | LED | 13.00 | 96644880 | ||||
| AFP M 48L35-740 A5 BS 3550 CL2 GY | 50 | 8321 | LED | 12.96 | 96644881 | ||||
| AFP M 48L50-740 A5 BS 3550 CL1 GY | 72 | 11437 | LED | 13.01 | 96644900 | ||||
| AFP M 48L50-740 A5 BS 3550 CL2 GY | 72 | 11437 | LED | 13.63 | 96644901 | ||||
| AFP M 48L70-740 A5 BS 3550 CL1 GY | 101 | 15299 | LED | 13.68 | 96644920 | ||||
| AFP M 48L70-740 A5 BS 3550 CL2 GY | 101 | 15299 | LED | 13.63 | 96644921 | ||||
| AFP M 72L35-740 A5 BS 3550 CL1 GY | 75 | 12439 | LED | 13.81 | 96644940 | ||||
| AFP M 72L35-740 A5 BS 3550 CL2 GY | 75 | 12439 | LED | 13.77 | 96644941 | ||||
| AFP M 72L50-740 A5 BS 3550 CL1 GY | 107 | 17053 | LED | 13.81 | 96644960 | ||||
| AFP M 72L50-740 A5 BS 3550 CL2 GY | 107 | 17053 | LED | 13.77 | 96644961 | ||||
| AFP M 72L70-740 A5 BS 3550 CL1 GY | 150 | 22709 | LED | 13.81 | 96644990 | ||||
| AFP M 72L70-740 A5 BS 3550 CL2 GY | 150 | 22709 | LED | 13.77 | 96644991 |
▼ Areaflood Pro Medium, Asymmetric optic 50°, DALI dimmable
| Description | Luminaire power (W) | Luminaire output (lm) | Type | Wt (kg) | SAP Code | ||||
|---|---|---|---|---|---|---|---|---|---|
| AFP M 48L35-740 A5 HFX CL1 GY | 50 | 8321 | LED | 13.97 | 96644894 | ||||
| AFP M 48L35-740 A5 HFX CL2 GY | 50 | 8321 | LED | 11.77 | 96644889 | ||||
| AFP M 48L50-740 A5 HFX CL1 GY | 72 | 11437 | LED | 13.97 | 96644914 | ||||
| AFP M 48L50-740 A5 HFX CL2 GY | 72 | 11437 | LED | 12.95 | 96644909 | ||||
| AFP M 48L70-740 A5 HFX CL1 GY | 101 | 15299 | LED | 13.65 | 96644934 | ||||
| AFP M 48L70-740 A5 HFX CL2 GY | 101 | 15299 | LED | 13.62 | 96644929 | ||||
| AFP M 72L35-740 A5 HFX CL1 GY | 75 | 12439 | LED | 13.78 | 96644954 | ||||
| AFP M 72L35-740 A5 HFX CL2 GY | 75 | 12439 | LED | 13.75 | 96644949 | ||||
| AFP M 72L50-740 A5 HFX CL1 GY | 107 | 17053 | LED | 13.78 | 96644984 | ||||
| AFP M 72L50-740 A5 HFX CL2 GY | 107 | 17053 | LED | 13.75 | 96644979 | ||||
| AFP M 72L70-740 A5 HFX CL1 GY | 150 | 22709 | LED | 13.78 | 96645022 | ||||
| AFP M 72L70-740 A5 HFX CL2 GY | 150 | 22709 | LED | 13.75 | 96645017 |
▼ Areaflood Pro Medium, Asymmetric optic 60°, bi-power
| Description | Luminaire power (W) | Luminaire output (lm) | Type | Wt (kg) | SAP Code | ||||
|---|---|---|---|---|---|---|---|---|---|
| AFP M 48L35-740 A6 BS 3550 CL1 GY | 50 | 8428 | LED | 13.00 | 96644882 | ||||
| AFP M 48L35-740 A6 BS 3550 CL2 GY | 50 | 8428 | LED | 12.96 | 96644883 | ||||
| AFP M 48L50-740 A6 BS 3550 CL1 GY | 72 | 11584 | LED | 13.01 | 96644902 | ||||
| AFP M 48L50-740 A6 BS 3550 CL2 GY | 72 | 11584 | LED | 13.63 | 96644903 | ||||
| AFP M 48L70-740 A6 BS 3550 CL1 GY | 101 | 15497 | LED | 13.68 | 96644922 | ||||
| AFP M 48L70-740 A6 BS 3550 CL2 GY | 101 | 15497 | LED | 13.63 | 96644923 | ||||
| AFP M 72L35-740 A6 BS 3550 CL1 GY | 75 | 12600 | LED | 13.81 | 96644942 | ||||
| AFP M 72L35-740 A6 BS 3550 CL2 GY | 75 | 12600 | LED | 13.77 | 96644943 | ||||
| AFP M 72L50-740 A6 BS 3550 CL1 GY | 107 | 17273 | LED | 13.81 | 96644962 | ||||
| AFP M 72L50-740 A6 BS 3550 CL2 GY | 107 | 17273 | LED | 13.77 | 96644963 | ||||
| AFP M 72L70-740 A6 BS 3550 CL1 GY | 150 | 23002 | LED | 13.81 | 96644992 | ||||
| AFP M 72L70-740 A6 BS 3550 CL2 GY | 150 | 23002 | LED | 13.77 | 96644993 |
▼ Areaflood Pro Medium, Asymmetric optic 60°, DALI dimmable
| Description | Luminaire power (W) | Luminaire output (lm) | Type | Wt (kg) | SAP Code | ||||
|---|---|---|---|---|---|---|---|---|---|
| AFP M 48L35-740 A6 HFX CL1 GY | 50 | 8428 | LED | 13.97 | 96644895 | ||||
| AFP M 48L35-740 A6 HFX CL2 GY | 50 | 8428 | LED | 11.77 | 96644890 | ||||
| AFP M 48L50-740 A6 HFX CL1 GY | 72 | 11584 | LED | 13.97 | 96644915 | ||||
| AFP M 48L50-740 A6 HFX CL2 GY | 72 | 11584 | LED | 12.95 | 96644910 | ||||
| AFP M 48L70-740 A6 HFX CL1 GY | 101 | 15497 | LED | 13.65 | 96644935 | ||||
| AFP M 48L70-740 A6 HFX CL2 GY | 101 | 15497 | LED | 13.62 | 96644930 | ||||
| AFP M 72L35-740 A6 HFX CL1 GY | 75 | 12600 | LED | 13.78 | 96644955 | ||||
| AFP M 72L35-740 A6 HFX CL2 GY | 75 | 12600 | LED | 13.75 | 96644950 | ||||
| AFP M 72L50-740 A6 HFX CL1 GY | 107 | 17273 | LED | 13.78 | 96644985 | ||||
| AFP M 72L50-740 A6 HFX CL2 GY | 107 | 17273 | LED | 13.75 | 96644980 | ||||
| AFP M 72L70-740 A6 HFX CL1 GY | 150 | 23002 | LED | 13.78 | 96645023 | ||||
| AFP M 72L70-740 A6 HFX CL2 GY | 150 | 23002 | LED | 13.75 | 96645018 |
▼ Areaflood Pro Large, Asymmetric optic 40°, bi-power
| Description | Luminaire power (W) | Luminaire output (lm) | Type | Wt (kg) | SAP Code | ||||
|---|---|---|---|---|---|---|---|---|---|
| AFP L 120L35-740 A4 BS 3550 CL1 GY | 124 | 21253 | LED | 17.08 | 96644542 | ||||
| AFP L 120L35-740 A4 BS 3550 CL2 GY | 124 | 21253 | LED | 17.04 | 96644543 | ||||
| AFP L 120L50-740 A4 BS 3550 CL1 GY | 177 | 29070 | LED | 18.43 | 96644562 | ||||
| AFP L 120L50-740 A4 BS 3550 CL2 GY | 177 | 29070 | LED | 18.39 | 96644563 | ||||
| AFP L 120L70-740 A4 BS 3550 CL1 GY | 249 | 38553 | LED | 18.43 | 96644582 | ||||
| AFP L 120L70-740 A4 BS 3550 CL2 GY | 249 | 38553 | LED | 18.39 | 96644583 | ||||
| AFP L 144L35-740 A4 BS 3550 CL1 GY | 149 | 25412 | LED | 18.52 | 96644602 | ||||
| AFP L 144L35-740 A4 BS 3550 CL2 GY | 149 | 25412 | LED | 18.48 | 96644603 | ||||
| AFP L 144L50-740 A4 BS 3550 CL1 GY | 211 | 34658 | LED | 18.52 | 96644622 | ||||
| AFP L 144L50-740 A4 BS 3550 CL2 GY | 211 | 34658 | LED | 18.48 | 96644623 | ||||
| AFP L 144L70-740 A4 BS 3550 CL1 GY | 297 | 45792 | LED | 18.52 | 96644652 | ||||
| AFP L 144L70-740 A4 BS 3550 CL2 GY | 297 | 45792 | LED | 18.48 | 96644653 | ||||
| AFP L 144L85-740 A4 BS 3550 CL1 GY | 360 | 51339 | LED | 18.72 | 96632326 | ||||
| AFP L 144L85-740 A4 BS 3550 CL2 GY | 360 | 51339 | LED | 18.72 | 96632327 | ||||
| AFP L 96L35-740 A4 BS 3550 CL1 GY | 98 | 17058 | LED | 17.36 | 96645046 | ||||
| AFP L 96L35-740 A4 BS 3550 CL2 GY | 98 | 17058 | LED | 17.32 | 96645047 |
