Olsys Street

  • Olsys Street
  • Olsys Street

Versatile and sober street lantern employing a state-of-the-art LED engine for performance and efficiency

  • State-of-the-art LED engine in line with EN13201 and European recommendations (ULOR 0%, above 70lm/W in 4000K) to cover projects up to ME3
  • Complete with power reduction to reduce energy consumption during the night
  • Exceptionally low cost of ownership with an optimised heat management system to provide a lifetime up to 80,000 hours (L70, 25°) without dimming
  • Discreet design is coordinated with Olsys Area luminaires and available with a wide choice of mounting types and column packages

Materials and Finish

Body: die-cast aluminium (AS9U), standard corrosion class: C3,
powder coated silver grey 9006 finish
Enclosure: size 1 clear UV stabilised PC
size 2: tempered glass
Optics: size 1 PC, size 2 micro reflectors in highly reflective anodised aluminium
Screws: stainless steel
Brackets and mounting accessories: aluminium

Installation and Mounting

Fitting and mounting accessories delivered sperately.
Product supplied pre-wired with connector
Recommended mounting heights:
Olsys Street 1: 4m
Olsys Street 2 : 6 to 8m
Coordinated columns and brackets: cylindro-conical or curved
Access to gear (replaceable) via 4 screws from the canopy
Suitable for ambient temperature range -30 to 50°C


To specify state:
IP66 LED street lantern with 24/45/70/90W (up to 7000Llm) LED packages, powder coated silver grey 9006, integrated dimming system and coordinated decorative columns and brackets.
As Thorn Olsys Street.

New Product
LumExpress Product
eControl Product

Olsys 1 street

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
OLSYS1 12L70 730 CL1 BP5 STR283160LED2.9096633538
OLSYS1 12L70 730 CL2 BP5 STR283160LED2.9096633537
OLSYS1 12L70 740 CL1 BP5 STR283315LED2.9096633536
OLSYS1 12L70 740 CL2 BP5 STR283315LED2.9096633535

Olsys 1 street, mounting accessories

Description   Wt (kg)SAP Code
<OLSYS1 MLE 60MA1.2096262297
OLSYS1 BRA 500MM MTP3.9096262300
OLSYS1 BRx2 1000MM MTP6.9096262301
OLSYS1 MLE 47MA1.0096262302
OLSYS1 MTP 60/761.4096262298
OLSYS1 MTP 60/76 x22.1096262299

Olsys 1 street, cylindro-conical columns

Description   Wt (kg)SAP Code
<OLSYS COL 4M CCO BRAx2 MPL FAI GRY40.0096262333
<OLSYS COL 4M CCO MPL FAI GRY40.0096262360

Olsys 2 street

DescriptionLuminaire power (W)Luminaire output (lm)   TypeWt (kg)SAP Code
OLSYS2 36L70 730 CL1 BP8 STR789895LED8.7596633550
OLSYS2 36L70 730 CL2 BP8 STR789895LED8.7596633549
OLSYS2 36L70 740 CL1 BP8 STR7810375LED8.7596633548
OLSYS2 36L70 740 CL2 BP8 STR7810375LED8.7596633547

Olsys 2 street, mounting accessories

Description   Wt (kg)SAP Code
OLSYS2 BRA 500MM MTP5.3096262306
OLSYS2 BRx2 1000MM MTP10.0096262307
OLSYS2 MLE 47MA2.5096262308
OLSYS2 MLE 60MA2.6096262303
OLSYS2 MTP 60/762.9096262304
OLSYS2 MTP 60/76 x25.0096262305
OLSYS2 MWA STR0.6096267967

Olsys 2 street, cylindro-conical columns

Description   Wt (kg)SAP Code
<OLSYS COL 6M CCO BRAx2 MPL FAI GRY92.0096262335
